Knob and tube wiring replacement cost typically ranges from a few thousand dollars to replace a handful of circuits to roughly $10,000 to $30,000 or more for a full rewire of an average-size older home, with plaster repair, a panel upgrade and permits often adding to the total. The biggest variables are the size of the house, how easily an electrician can fish new cable through finished walls, and how much of the original wiring is still energized. Because knob and tube systems date mostly from the late 1800s into the 1940s, these are older homes with their own complications, from plaster walls to lead-based paint. This guide covers typical national price ranges, what pushes quotes up or down, when partial replacement is reasonable, how to read an electrician’s estimate and what Front Range buyers and owners should know. Figures are general ranges for 2026, not quotes, and local prices vary.

Part of our Home Electrical guide — start there for the full picture →

Knob and Tube Replacement Cost at a Glance

Our parent guide to knob and tube wiring explains how the system works and why it raises concern today. The table below shows how replacement work is typically priced.

Per-square-foot pricing is common for whole-house rewiring, but it hides big differences. A single-story bungalow with an open attic and unfinished basement can be much cheaper to rewire than a two-story home of the same size with finished spaces above and below the main floor.

Why Knob and Tube Wiring Gets Replaced

Knob and tube wiring was not inherently unsafe when it was installed. The problems come from age, alteration and modern use.

• No equipment ground. The system has no grounding conductor, so three-prong receptacles connected to it are not truly grounded unless additional protection has been added. The U.S. Fire Administration warns never to force a three-prong cord into a two-slot outlet.
• Aging insulation. The cloth and rubber insulation on the conductors can become brittle and crack, especially where it has been disturbed or exposed to heat.
• Amateur splices and extensions. Decades of additions often leave modern cable spliced into old conductors, sometimes outside junction boxes.
• Buried in insulation. The system was designed to shed heat into open air. Attic or wall insulation installed over or around it can trap heat.
• Limited capacity. Few circuits and modern loads, such as kitchens full of appliances, invite overloading and oversized fuses.
• Insurance and lending pressure. Some insurers and lenders ask about active knob and tube wiring, and some may require an electrician’s evaluation or replacement before writing or renewing coverage. Policies vary, so ask your insurer directly.

Electrical malfunctions are a significant source of home fires. The U.S. Fire Administration’s national estimates for 2023 report 23,700 residential building electrical malfunction fires, 305 deaths, 800 injuries and about $1.5 billion in dollar loss. Those figures cover all residential electrical malfunctions, not only older wiring, but they show why insurers and inspectors take wiring condition seriously.

What Drives the Cost of Replacement

House size and circuit count

More rooms and more circuits mean more cable, more boxes and more labor. Modern code requirements usually mean the new system will have far more circuits than the original, including dedicated kitchen, bathroom and laundry circuits.

Access to walls and ceilings

Labor is the largest piece of a rewire. Electricians fish new cable through existing walls from an accessible attic or basement when they can. Finished basements, cathedral ceilings, second floors with no attic access above, and fire blocking inside walls all force more openings and more time.

Plaster and lath

Many knob and tube homes have plaster on wood or metal lath. Plaster is harder to cut cleanly than drywall and more expensive to patch well. Some electricians include basic patching; others leave holes for a plasterer or drywall contractor. Make sure the quote spells out which.

Panel and service

Many older homes still have fuse boxes or undersized services. Replacing a whole system of branch wiring often goes hand in hand with a new panel and sometimes a service upgrade, which adds cost but may be necessary to support the new circuits.

Code-required protection

New circuits typically need modern protection such as GFCI protection in kitchens, bathrooms, garages, basements and outdoors, and AFCI protection in many living areas, plus smoke alarms and, where required, carbon monoxide alarms. NFPA recommends asking a licensed electrician to install AFCI protection if it is not already in place, and to install GFCIs in bathrooms, kitchens, garages and basements, with all outdoor receptacles GFCI-protected. These devices cost more than standard breakers and receptacles but are part of a code-compliant job.

Lead-based paint and other old-house issues

Cutting into painted surfaces in a pre-1978 home can create lead dust. EPA’s Renovation, Repair and Painting Rule requires that anyone paid to perform work that disturbs painted surfaces in homes built before 1978 be certified and follow lead-safe work practices. That can add containment and cleanup time to the bill. Older homes may also contain asbestos in some materials, so ask how the contractor will handle suspect materials before walls are opened.

Occupancy and scheduling

Rewiring an empty house goes faster than working around a family. Some electricians offer phased work so part of the house stays powered, which is more convenient but can extend the timeline and cost.

Partial Replacement or Full Rewire?

There is no single right answer. These rules of thumb are commonly used, but an electrician’s evaluation of the actual system should drive the decision.

• Find out how much is still active. Many homes have had most of their original wiring replaced over the years. An electrician may find only a few remaining circuits, which makes a targeted replacement reasonable.
• Prioritize the riskiest areas. Circuits buried in attic insulation, those with visible damage, those feeding kitchens, bathrooms or high-load rooms, and any with amateur splices are logical first targets.
• Consider the renovation timeline. If walls will be opened for a kitchen or bath remodel, rewiring those rooms at the same time avoids paying to open and patch twice.
• Compare totals, not just the first phase. As a rule of thumb, if partial work quoted over several phases approaches the cost of a full rewire done at once, the single project often comes out cheaper overall.
• Factor in insurance. If an insurer requires all active knob and tube wiring to be removed, partial replacement may not satisfy the condition.

Our guide to house rewiring cost covers whole-home rewiring more broadly, including homes with other outdated wiring types. Homes from the mid-1960s to the mid-1970s may have aluminum branch wiring instead, which has different repair options; our guide to aluminum wiring explains the differences.

Warning Signs That Need Prompt Attention

Whether or not a full rewire is planned, some symptoms should be checked soon. NFPA’s electrical safety tips advise calling a qualified electrician for:

• Frequent problems with blowing fuses or tripping circuit breakers
• A tingling feeling when touching an electrical appliance
• Discolored or warm wall outlets
• A burning or rubbery smell coming from an appliance
• Flickering or dimming lights
• Sparks from an outlet

Oversized fuses, such as a larger fuse installed after a smaller one kept blowing, are another serious warning sign in older fuse panels. Homeowners should not attempt to rework old wiring themselves.

What Happens During a Knob and Tube Rewire

Knowing the sequence of a typical project helps homeowners plan around it and understand where the labor hours go.

1. Evaluation and circuit mapping. The electrician identifies which circuits are still knob and tube, which have been replaced, and how the existing panel is laid out. A good evaluation includes the attic, basement or crawlspace and a sample of outlets and fixtures.
2. Design and permit. The new layout is planned to current requirements, often adding circuits for kitchens, bathrooms and laundry. The electrician applies for the permit.
3. Prep and protection. Furniture is moved, floors are covered and, in pre-1978 homes, lead-safe containment is set up where painted surfaces will be disturbed.
4. Rough-in. New cable is fished through walls and ceilings, new boxes are installed and openings are cut where access is needed. This is the longest and messiest phase.
5. Rough-in inspection. Many jurisdictions require the inspector to see the new wiring before walls are closed.
6. Disconnect the old system. The old conductors are disconnected and abandoned in place where they cannot be removed without major demolition. They should no longer be connected to any power source.
7. Trim-out. Devices, fixtures, breakers, GFCI and AFCI protection and alarms are installed and tested.
8. Final inspection and patching. After the final inspection, walls and ceilings are patched and painted by whoever the contract assigns.

Abandoned knob and tube conductors left inside walls are normal after a rewire. What matters is that none of it remains energized. Ask the electrician to confirm this in writing, since future inspectors and insurers may see the old knobs and want to know their status.

Selling or Buying a Home With Knob and Tube Wiring

For sellers, documentation is the most valuable asset. A permit record, the electrician’s invoice describing what was replaced and a written statement that no active knob and tube remains can smooth negotiations considerably. Without it, buyers may assume the worst-case scope and price their requests accordingly.

For buyers, a seller’s statement that the house “was rewired” is a starting point, not proof. Ask when, by whom, whether a permit was pulled and whether the whole house or only part of it was done. Partial rewires are common, and an older attic or basement may still show active runs. Building an electrician’s estimate into the inspection period gives a realistic number for repair requests or credits and helps avoid surprises with insurance before closing.

How to Read a Knob and Tube Replacement Quote

Ask for two or three written quotes from licensed electricians with experience in older homes. A complete quote makes comparison possible.

Line items to look for

• The number of circuits being replaced and which rooms each serves
• Whether all knob and tube wiring will be disconnected and abandoned, or only some
• Cable type and gauge, and the number of new outlets, switches and fixtures
• GFCI and AFCI protection, smoke alarms and carbon monoxide alarms where required
• Panel work, including whether a new panel or service upgrade is included
• Permit, rough-in inspection and final inspection
• Who patches walls and ceilings, and to what finish level
• Lead-safe work practices for pre-1978 homes
• Expected duration and how power will be managed during the work
• Warranty terms

Red flags

• No permit. Rewiring is normally permitted work. Unpermitted rewiring may not satisfy insurers or buyers and skips an independent inspection.
• “Grounding” by swapping receptacles. Installing three-prong outlets on ungrounded circuits without proper protection or labeling is not a fix.
• Vague scope. A per-house price without a circuit count or room list makes it impossible to know what is included.
• Pressure to decide today. Active hazards should be addressed promptly, but a rewire is a large project worth comparing.
• Unrelated upsells. Whole-house surge packages, smart-home add-ons or generator hookups may be worthwhile, but they belong as separate line items you can accept or decline.

Questions to ask

• How much active knob and tube wiring did you find, and how did you verify it?
• Will any old wiring remain energized after your work?
• How many wall and ceiling openings do you expect, and who closes them?
• Does the panel need to be replaced, and why?
• Can you provide documentation for my insurer when the job is finished?

Front Range Considerations

Knob and tube wiring along the Front Range is concentrated in the oldest neighborhoods of Denver, Boulder, Colorado Springs, Fort Collins, Pueblo and older town centers across the region. A few local factors are worth knowing:

• Attic insulation upgrades. Colorado’s cold winters make attic insulation attractive, and ENERGY STAR notes that sealing air leaks and adding insulation can provide up to a 10 percent savings on annual energy bills. But insulation should not be blown over active knob and tube wiring without guidance from an electrician and the local building department. Replacing the wiring first often makes the insulation project simpler.
• Dry winter air. Very low humidity can make brittle old insulation on conductors more fragile when disturbed, so avoid moving or pulling on exposed wires in attics and basements.
• Permits and inspections. Requirements for electrical permits and inspections vary by municipality. Check with your city or county building department before hiring.
• Historic districts. Homes in historic districts may have extra review for exterior changes, such as a new service mast or meter location, even though interior rewiring itself is normally a standard permit.

How a Home Inspection Flags Knob and Tube Wiring

The ASHI Standard of Practice directs home inspectors to inspect service equipment, conductors, overcurrent protection devices and a representative number of fixtures, switches and receptacles, and to describe the predominant branch circuit wiring method. A general inspection is visual. An inspector may see ceramic knobs and tubes in an unfinished basement or attic, cloth-insulated conductors, two-slot receptacles, ungrounded three-prong receptacles, a fuse panel or signs of overheating, but cannot open walls to confirm how much wiring remains.

When an inspection report notes knob and tube wiring, the usual next step is a detailed evaluation by a licensed electrician. Our guide to an electrical inspection explains what that deeper review can include, and infrared scanning, covered in our guide to infrared thermography electrical inspection, can help spot hot connections under load. For more on who to call for wiring issues, see our electrical hiring guides.

For buyers, the timing matters. Getting an electrician’s estimate during the inspection period gives a realistic number to use in negotiation and helps confirm whether the home will be insurable on the expected timeline.

Ways to Manage the Cost

• Get an evaluation first so quotes are based on what is actually present.
• Combine rewiring with planned remodels, insulation work or painting.
• Do non-electrical prep, such as clearing attic storage and moving furniture, to save labor hours.
• Ask whether patching to a paint-ready finish is cheaper through the electrician or a separate drywall contractor.
• Plan the panel and circuit layout for future needs, such as a heat pump or vehicle charger, so walls do not need to be opened again.
