A solar tube, also called a tubular skylight, sun tunnel or tubular daylighting device, brings daylight into a room through a small dome on the roof and a reflective tube that runs through the attic to a diffuser in the ceiling. Because the roof opening is small and no light well has to be framed, solar tubes are often chosen for hallways, bathrooms, closets and interior rooms where a full skylight would be impractical. They are not maintenance-free, however. Each one is a hole in the roof and a duct through a cold attic, so flashing, condensation, hail and installation quality all matter. This guide explains how solar tubes compare with conventional skylights, where they tend to leak, why tubes can drip in winter, how they fare in Colorado hail, what changes on different roof types, how to think about energy claims, and what installation and repair typically cost.

Part of our Structure & Exterior guide — start there for the full picture →

What a Solar Tube Is and How It Works

A solar tube has three main parts. On the roof, a clear dome, usually acrylic or polycarbonate, sits on a flashing base that seals to the roofing. Below the dome, a tube with a highly reflective interior surface runs down through the attic, either straight or with angled adapters to dodge framing, ducts or wiring. At the ceiling, a diffuser lens spreads the light into the room below.

Light enters the dome, bounces down the reflective tube and exits through the diffuser. Because the tube is reflective rather than transparent, it can carry useful light through several feet of attic, although longer runs and more elbows reduce output. Common residential sizes have roof openings that are much smaller than a typical skylight, which is part of why installation is simpler.

Some models add accessories such as a dimmer baffle to close off light, an integrated light fixture for nighttime use, or a small ventilation fan. Each accessory adds a component that may need maintenance or electrical work.

Solar Tubes vs Skylights

The two products solve the same problem in different ways.

Size and framing

A conventional skylight requires cutting one or more rafters or trusses in many cases, framing a curb or opening, and building a drywall light shaft through the attic to the ceiling. A solar tube usually fits between existing framing members and replaces the light shaft with a pre-made tube. That generally means less structural work and a shorter installation.

Light quality and view

A skylight provides a direct view of the sky and more light overall, especially with larger units. A solar tube provides diffused light with no view. Many people find tube light pleasant in small spaces, but it does not replace a window or full skylight in a large room.

Heat gain and loss

A large glazed skylight can add significant heat gain in summer and heat loss in winter depending on its glazing and orientation. Solar tubes have a smaller opening, which limits exposure, but the tube itself passes through an unconditioned attic and can lose heat to it. Insulation around the tube and a tight ceiling seal help.

Venting

Many skylights can open for ventilation. Solar tubes generally do not, unless a model includes a fan kit.

The sibling guide on skylight replacement covers the larger product in more depth.

Flashing and Roof Leaks

Most solar tube leaks start at the roof, not at the dome. The flashing base has to integrate with the roofing so water running down the slope is shed over the top of the flashing on the downhill side and directed around it on the uphill side. On a shingle roof, that usually means the upper part of the flashing goes under the shingles above, and the lower part sits on top of the shingles below.

Common leak causes include:

• Flashing installed on top of upslope shingles instead of tucked under them, letting water run beneath the base.
• Sealant used in place of proper flashing, which works briefly and then cracks.
• Damaged or lifted shingles around the base after wind, hail or later roof work.
• Cracked or loose domes that let water drip into the tube.
• Debris and ice dams piling up on the uphill side of the base and pushing water under the roofing.

The roof flashing guide explains how step flashing, counterflashing and penetration flashing should be layered. The skylight leak guide covers how to tell a flashing leak from condensation, which matters for tubes as much as for skylights.

The American Society of Home Inspectors Standard of Practice lists skylights, chimneys and roof penetrations among the items inspectors are required to inspect under roofing, along with flashing. Inspectors also describe the methods used to inspect the roof, since some roofs are viewed from the ground or with a drone rather than walked.

Condensation in Solar Tubes in Cold Attics

Water dripping from a solar tube diffuser in winter is not always a roof leak. Often it is condensation. The tube passes through an attic that, in a Colorado winter, may be well below freezing. Warm, moist indoor air that reaches the cold inner surface of the tube or dome can condense and freeze, then melt and drip on sunny days.

Moist air reaches the tube in a few ways:

• Gaps between the diffuser assembly and the ceiling drywall let room air rise into the tube.
• Loose joints between tube sections let attic or room air circulate inside.
• High indoor humidity from showers, cooking, humidifiers or poor bath fan performance.

The EPA’s A Brief Guide to Mold, Moisture and Your Home notes that condensation can be a sign of high humidity, and advises keeping indoor humidity below 60 percent, ideally between 30 and 50 percent. It also suggests running bathroom fans when showering, venting moisture-producing appliances outside and insulating cold surfaces to help prevent condensation.

ENERGY STAR’s Attic Air Sealing Project describes the same mechanism elsewhere in the attic: in cold weather, frosty areas may appear in insulation where warm, moist air condenses and freezes as it meets cold attic air. For solar tubes, practical fixes include sealing the ceiling ring to the drywall, taping tube joints per the manufacturer’s instructions, wrapping the tube in insulation where the manufacturer allows it, and managing bathroom humidity. Many manufacturers sell insulating sleeves for this purpose.

Attic conditions matter too. Poor attic ventilation or a warm attic can contribute to both condensation and ice dams around the dome. The attic ventilation guide and the ice dams guide explain how to keep the roof deck cold and dry in winter.

Hail and Solar Tube Domes

The Front Range sees frequent hail, and solar tube domes sit right in its path. Polycarbonate and impact-modified acrylic domes are common, and some manufacturers publish impact ratings, but no dome is immune to large hail. After a storm, look for:

• Cracks, crazing or holes in the dome.
• Dents or bends in the metal flashing base.
• Damaged shingles around the base.
• Water stains on the diffuser or ceiling below.

Replacement domes are often available separately from the full kit, which can keep repair costs down. If the roof is being evaluated for hail damage, include the solar tubes and their flashing in the claim documentation. The hail damage roof guide covers what to photograph and when to call an inspector or adjuster.

Hail damage to a dome is not always obvious from the ground. A small puncture or a hairline crack may let water into the tube only during wind-driven rain, and the first sign can be a stain on the diffuser weeks later. Older acrylic domes can also turn brittle and cloudy from years of ultraviolet exposure at high altitude, which makes them more likely to crack in the next storm. When a roofer or adjuster is already on the roof after a hailstorm, asking them to look closely at each dome costs little and documents its condition.

Installation on Different Roof Types

Manufacturers typically offer different flashing bases for different roofing materials, and using the right one is the single biggest factor in a leak-free install.

Asphalt shingles

The most common installation. A standard flashing base slides under upslope shingles and over downslope shingles. Careful cutting and sealing of nails is still required.

Tile roofs

Clay and concrete tile require a tile-specific flashing kit, and tiles are brittle to walk on. Installations often involve removing and resetting tiles, which raises labor cost and breakage risk.

Metal roofs

Standing seam and corrugated metal roofs may need a curb or a specialty flashing that matches the panel profile. Cutting metal panels and sealing them correctly is a job for someone experienced with that roof type.

Low-slope and flat roofs

Low-slope roofs usually need a raised curb so the dome sits above standing water and the roofing membrane can be properly integrated.

Roof age

Installing a solar tube on a roof near the end of its life often makes little sense, because the flashing will need to be redone at the reroof. Timing tube installation with a roof replacement can save money and reduce leak risk.

Energy Use and ENERGY STAR

Solar tubes are often marketed as energy savers because daylight can reduce the need for electric lighting during the day. How much that matters depends on the room, the hours it is used and the lighting it replaces. With efficient LED lighting, the electricity savings from daylighting a single hallway may be small. Claims of specific dollar savings should be treated with caution unless they come from independent testing.

ENERGY STAR’s Residential Windows, Doors and Skylights page explains that certified skylights are independently certified and must meet U-factor and, where applicable, solar heat gain coefficient requirements based on climate zone, and advises shoppers to look for the ENERGY STAR label next to the NFRC label. The same page lists skylights among the openings where air can leak, and notes that even the best products can be drafty if poorly installed. Buyers of a solar tube can ask the manufacturer for NFRC ratings or other performance documentation for the specific model rather than assume it carries the same certification as a skylight.

Typical Solar Tube Costs

Prices vary by region, roof type, tube length and accessories. The ranges below are informal estimates:

• DIY kit: commonly a few hundred dollars for a standard residential size, more for larger diameters or added accessories.
• Professional installation on a shingle roof: often several hundred to over a thousand dollars per unit including the kit, depending on tube length and attic access.
• Tile, metal or low-slope roof: generally higher because of specialty flashing and labor.
• Replacement dome after hail: usually a fraction of the full kit price, plus labor if a roofer installs it.
• Leak repair or reflashing: varies with roof type and access.

Getting at least two bids and asking whether the price includes insulating the tube and sealing the ceiling ring helps compare offers fairly.

Choosing Where to Put a Solar Tube

Placement affects both light output and long-term reliability. A few planning points come up repeatedly:

• Roof orientation. South-facing roof planes generally deliver more light through the day in the Northern Hemisphere, though many domes are designed to capture low-angle light from other directions as well.
• Tube length and bends. The shorter and straighter the run, the more light reaches the room. Each angled adapter reduces output.
• Attic obstacles. Ducts, wiring, plumbing vents and trusses can force a longer or more angled path. A quick look into the attic before buying helps avoid surprises.
• Distance from valleys and chimneys. Placing a dome in a valley or just below a chimney concentrates water and debris against the flashing. A spot on an open roof plane is usually safer.
• Snow and shade. Domes on north-facing or shaded slopes may hold snow longer, which can reduce light and add ice around the base.
• Room use. Bathrooms produce the most humidity, so tubes there benefit most from careful sealing and a working exhaust fan.

Where the attic is very shallow, such as a low-slope roof over a vaulted room, a short rigid tube or a different daylighting product may fit better than a long flexible run.

Maintenance and Inspection Checklist

Solar tubes need little routine care, but a seasonal look catches problems early. A practical checklist for homeowners:

1. From the ground, after storms: scan the dome with binoculars for cracks, haze or missing pieces.
2. From inside, each season: check the diffuser and surrounding ceiling for stains, drips, bubbled paint or dead insects, which can indicate a gap in the dome or tube.
3. In the attic, once a year: look at the tube joints, the insulation sleeve and the area around the ceiling ring for frost, water stains or displaced insulation.
4. On the roof, during routine roof maintenance: have the roofer clear debris from the uphill side of the base and confirm the flashing and surrounding shingles are intact.
5. Cleaning: follow the manufacturer’s guidance for cleaning the dome and diffuser; abrasive cleaners can scratch acrylic and polycarbonate.

Climbing on a roof carries real fall risk, especially on steep or snowy slopes. Rooftop checks are best left to roofers or inspectors with proper equipment.

Solar Tubes When Buying a Home

During a home inspection, solar tubes are typically evaluated as roof penetrations. Inspectors look at the dome and flashing from wherever the roof is viewed, check the ceiling diffuser for staining and, where the attic is accessible, look at the tube itself. Buyers may want to ask the seller when the tubes were installed, whether they were part of a roof replacement, whether any domes have been replaced after hail, and whether any leaks have been repaired. Because a tube that leaks only in heavy rain or only during freeze-thaw cycles may look fine on inspection day, old ceiling repairs near the diffuser are worth asking about.

When to Call a Professional

Water on a diffuser, a stained ceiling ring or ice on the dome are signs worth investigating. An inspection can help determine whether the cause is flashing, the dome or condensation, and whether surrounding roofing or attic conditions are contributing. The guide to hiring a home inspector explains how to choose an inspector, and the structure and exterior hub collects related roof, attic and exterior topics.

References

• Standard of Practice for Home Inspections — American Society of Home Inspectors
• A Brief Guide to Mold, Moisture and Your Home — U.S. Environmental Protection Agency
• Attic Air Sealing Project — ENERGY STAR
• Residential Windows, Doors and Skylights — ENERGY STAR
