Radon Vent: Fan, Pipe, Passive Vents and Installation
A radon vent is the sealed pipe, usually 3- or 4-inch Schedule 40 PVC, that carries radon-laden soil gas from a suction point under the foundation to an exhaust above the roof edge. In an active system an inline radon vent fan mounted in the attic, garage or outdoors pulls gas through that pipe around the clock; in a passive system the pipe relies on warm-air buoyancy alone. This guide summarizes EPA and Colorado Department of Public Health and Environment guidance current as of 2026; vent design depends on each home’s foundation, so consult a certified radon professional for system decisions and your physician for any health questions.
Part of our Radon Mitigation Systems guide — start there for the full picture →
Homeowners usually notice the vent long before they understand it: a white pipe climbing an exterior wall, a capped stub in the attic of a new build, or a small gauge on a basement pipe with colored liquid in it. This guide focuses on that hardware itself, the pipe, the fan, the gauge and the exhaust, and how to tell a correctly built radon vent system from one that only looks the part. For the broader picture of how radon is drawn out of a home, see the radon removal methods guide.
Radon Vent System: The Parts and What Each Does
A radon vent system is a short list of components working together. Each one has a job, and a failure in any of them weakens the whole system.
| Component | Job | What a good install looks like |
|---|---|---|
| Suction point | Opening into the soil under the slab, sump or crawl-space membrane | Core hole with a small excavated pit, pipe sealed into the concrete with urethane caulk |
| Vent pipe | Carries soil gas from the suction point to the exhaust | 3- or 4-inch Schedule 40 PVC, solvent-welded joints, sloped to drain, labeled |
| Radon vent fan | Creates continuous suction (active systems only) | Rated inline radon fan in attic, garage or outdoors; never in a basement or living space |
| Manometer | Shows whether the fan is creating suction | U-tube gauge on the pipe at eye level, starting reading marked |
| Exhaust (termination) | Releases gas where it disperses safely | Above the roof edge, well clear of windows, doors and air intakes |
| Electrical | Powers the fan | Hard-wired or outdoor-rated connection with a disconnect within sight of the fan |
| Label | Identifies the system for future owners and trades | System label near the gauge with installer details and date |
Radon Vent Pipe
The radon vent pipe is almost always rigid PVC, either 3-inch or 4-inch diameter. Schedule 40 is the standard because its thick walls resist impact, hold solvent-welded joints well and stand up to years of continuous suction. Thin-wall drain pipe or flexible corrugated hose are poor substitutes: the thin pipe cracks and the corrugated ridges cause turbulence, noise and trapped condensation.
Four-inch pipe is common because it moves the same airflow at lower velocity, which means less resistance, less noise and less work for the fan. Three-inch pipe is often used for interior runs where space is tight, such as inside a closet or wall chase. The installer sizes the pipe to the fan and to the airflow the soil allows.
Slope and condensation
Soil gas is warm and humid. When it rises into a cold attic or an exterior run during a Front Range winter, water condenses on the inside of the pipe. A correctly built vent slopes continuously back toward the suction point so that water drains down into the soil. A sag or a horizontal run with no fall lets water pool, which restricts airflow, makes gurgling noises and can freeze solid. Horizontal sections should be supported at regular intervals and pitched back toward the slab.
Labeling and joints
Industry standards call for the pipe to be labeled as part of a radon system so that a future plumber or remodeler does not cut into it or mistake it for a drain line. All joints below the fan should be solvent-welded and airtight; the fan connects with rubber couplings so it can be swapped later without cutting pipe.
Exterior pipe in sun and cold
PVC exposed to sunlight degrades slowly, so exterior runs are often painted with exterior latex paint or enclosed in a downspout-style cover. In very cold areas some installers insulate attic sections to limit condensation and the risk of ice forming near the exhaust.
Radon Vent Fan
The radon vent fan turns a passive pipe into an active system. It is an inline fan with a sealed housing, built for continuous duty and for moist soil gas. Fans are grouped loosely by what they do best:
- High-flow, lower-suction fans suit homes with a porous gravel layer under the slab, where air moves easily.
- Medium-suction fans are the general-purpose choice for most basements and slabs.
- High-suction fans suit tight clay soils, large slabs or long sub-slab distances, where the fan must pull hard to extend the pressure field.
Manufacturer specifications show residential radon fans drawing anywhere from tens of watts to around 150 watts. A diagnostic pressure test lets the installer choose the smallest fan that does the job, which keeps electricity use and noise down.
Where the fan goes
The single most important fan rule is location. The fan must sit outside conditioned living space and not in a basement, because the pipe downstream of the fan is under positive pressure. A cracked joint on that side would push radon into the house. Acceptable locations are an attic, an attached garage with no living space above it, or the exterior of the house. The fan should be mounted vertically so condensation can drain through it.
Fan noise and vibration
A properly mounted radon vent fan produces a low hum. Noise problems usually come from the fan touching framing, a pipe strapped too tightly to a wall that transmits vibration, or high airflow through a small pipe. Rubber couplings, isolated mounting and a larger pipe diameter generally quiet things down. Readers comparing models by suction, airflow and wattage can use the best radon fan roundup.
Passive Radon Vent
A passive radon vent is a pipe that runs from beneath the slab to the roof with no fan. It depends on the stack effect: soil gas warmed by the house rises through the pipe on its own. Passive vents are usually installed during construction as part of radon-resistant new construction, which typically pairs the pipe with a gas-permeable gravel layer under the slab, a polyethylene sheet over the gravel, and sealed slab openings. The radon-control appendix of the International Residential Code describes this approach, including a vent pipe from the gravel layer through the roof and an electrical junction box in the attic for a future fan.
Passive vents lower radon but often not by enough in high-radon regions such as the Front Range. Their real value is that the hard part, the suction point and the pipe route, is already finished. If a home with a passive vent tests at or above the EPA action level of 4.0 pCi/L, adding a fan in the attic converts it to an active system, which is among the cheapest radon fixes available.
How to spot a passive radon vent
- A capped or open 3- or 4-inch PVC pipe in the attic, often running through the roof, with no fan attached.
- A pipe labeled “radon” in a basement closet or utility room running straight up.
- An unused electrical outlet or junction box in the attic near that pipe.
- A roof penetration that looks like a plumbing vent but rises from a dedicated pipe rather than the drain stack.
A home with a passive vent should still be tested. Many buyers assume the pipe means radon is handled; it only means the home is ready to be handled if the test reads high.
Active vs Passive Radon Vent: Comparison
| Factor | Passive radon vent | Active radon vent (with fan) |
|---|---|---|
| Driving force | Stack effect only; varies with weather and season | Continuous fan suction |
| Typical reduction | Modest and variable | Large and consistent; EPA cites soil suction reductions of up to 99% |
| Electricity | None | Fan runs 24/7 |
| Monitoring | Usually none | Manometer shows suction at a glance |
| When it is installed | During construction | Retrofit or activation of a passive vent |
| Upgrade path | Add a fan in the attic | Larger fan or added suction point if needed |
Radon Vent Installation
Radon vent installation in an existing home usually takes about a day. The steps below describe a typical sub-slab job; sump and crawl-space installs follow the same pattern with a different suction point.
- Diagnose the slab. Small test holes and a pressure gauge show how far suction will travel under the floor, which sets the number of suction points and the fan size.
- Plan the route. The installer chooses an interior route (closet, chase, garage, then attic and roof) or an exterior route (out the rim joist and up the side wall). The radon piping layout guide compares the options.
- Core the slab and dig the pit. A hole is cored through the concrete and some soil or gravel is removed beneath it to open up the suction field.
- Set and seal the pipe. The vent pipe drops into the hole and is sealed to the slab with urethane caulk or a similar sealant.
- Run the pipe. Joints are solvent-welded, horizontal runs are pitched back toward the slab, and the pipe is strapped and supported.
- Mount the fan. The fan goes in the attic, garage or outdoors with rubber couplings, followed by the electrical connection and a disconnect.
- Terminate the exhaust. The pipe continues above the roof edge, clear of openings, as described in the next section.
- Seal and label. Major slab cracks, the floor-wall joint where accessible, and the sump are sealed; the manometer and system label go on.
- Retest. A post-mitigation radon test starts at least 24 hours after the fan is switched on to confirm the result.
Homes with a sump basket often use it as the suction point, with a sealed lid; the radon mitigation with a sump pump guide explains how the lid and pump coexist. Crawl spaces need a sealed membrane first, covered in the crawl space radon mitigation guide. Standard slab installs are detailed in the sub-slab radon mitigation system guide.
Where the Radon Vent Exhaust Must Terminate
The exhaust point is the detail most often done wrong, and a bad termination can send radon straight back into the house. EPA guidance and the ANSI/AARST residential mitigation standards set the general rules. Exact figures vary by standard edition and local code, but the common requirements are:
- Above the roof edge. The exhaust should discharge above the eave of the roof, so the gas rises and disperses away from the house.
- Well above the ground. Standards typically require the exhaust to sit at least 10 feet above ground level.
- Away from openings. It should be at least 10 feet horizontally from windows, doors and other openings, unless it sits well above them, and away from neighboring homes.
- Clear of air intakes. Furnace, water-heater and HRV fresh-air intakes must not be able to pull the exhaust back in.
- Pointing up and unobstructed. Caps that deflect the exhaust downward toward the roof or eaves are discouraged; the gas should be released upward.
A vent that ends at ground level, under a deck, below a window or beneath a roof overhang is a red flag. Correcting the termination is a common, relatively inexpensive fix.
Radon Vent Kit
A radon vent kit bundles the parts a do-it-yourselfer needs for a basic active system. Contents vary, but most include:
- An inline radon fan, sometimes with a choice of suction rating.
- Rubber couplings to connect the fan to the pipe.
- A U-tube manometer and system label.
- A suction-point seal or slab collar, and sometimes a sump lid.
- Mounting hardware; pipe and fittings are usually bought separately.
A kit can work well in an unfinished basement with an accessible sump or a slab over gravel, where routing is short and simple. Where kits fall short is design: choosing the fan size without a pressure test, coring concrete, sealing correctly, wiring the fan to code and placing the exhaust in a compliant spot. Some municipalities require a permit or a certified installer, and a self-built system can raise questions at resale. Whoever installs it, a post-mitigation test is the only proof it works. Pricing for kits versus professional installation is broken down in the cost to install a radon mitigation system guide.
Interior vs Exterior Radon Vent Routing
Both routes work when built correctly. The choice is mostly about appearance, cost and climate.
- Interior routing runs the pipe up through a closet, chase or garage into the attic, where the fan sits, then out through the roof. It hides the hardware and keeps the pipe warmer, which reduces freezing risk. It takes more labor and needs a roof penetration.
- Exterior routing exits the rim joist near the suction point and climbs the outside wall to a fan mounted outdoors, ending above the eave. It is usually faster and cheaper to install but visible, and the pipe is more exposed to cold, sun and ice.
In finished basements, the interior route often depends on whether a closet or utility room lines up with a path to the attic. Where nothing lines up, exterior routing through the rim joist avoids cutting into finished walls and ceilings.
What a home inspector checks on a radon vent
During a purchase inspection, the radon vent gets a quick but specific look. Inspectors typically confirm that the fan sits outside the living space, that the manometer shows suction, that the pipe is labeled and supported, that joints below the fan are sealed, and that the exhaust terminates above the roof edge and away from windows. They also ask for the most recent post-mitigation test. A vent that passes all of these checks but has no recent test result still leaves a question open, so many buyers order a fresh radon test during the inspection period regardless of what equipment is present. A missing gauge, a fan in the basement or a ground-level exhaust is commonly written up as a repair item for the seller to correct before closing.
Radon Vent Problems and Troubleshooting
Reading the manometer
The manometer is a U-shaped tube with colored liquid. When the fan creates suction, the liquid sits higher on one side. If both sides are level, the fan has stopped or the pipe is disconnected. Mark the starting position after installation; a reading that drifts toward zero over months suggests a blockage, a failing fan or a leak, while a reading that rises sharply can point to water or ice restricting the pipe.
Gurgling, dripping or icing
Gurgling usually means water sitting in a low spot. Dripping from the exhaust in cold weather is normal condensation, but a growing ice ring at the roof termination can partially block the pipe. Proper slope, attic insulation and a larger exhaust diameter reduce icing.
Radon still high with a vent in place
Common causes are a passive vent with no fan, a fan too weak for the soil, an unsealed sump or floor drain letting the fan pull basement air, a second foundation section with no suction point, or an exhaust re-entering through a nearby window. Each has a straightforward fix once diagnosed.
Fan has stopped
Check the breaker and the disconnect first. If power is present and the fan is silent, it likely needs replacement. Because rubber couplings hold it in place, a swap is usually quick.
Maintaining a Radon Vent
A well-built radon vent needs little attention. Glance at the manometer every month or two, keep the exhaust clear of debris and nests, listen for changes in fan sound, and retest the home every two years and after major renovations. Many fans run a decade or more, but plan for an eventual replacement. When selling, keep the installation paperwork and recent test results handy; buyers’ inspectors check the termination, fan location, label and manometer.
Along the Front Range, where CDPHE reports that roughly half of homes test above the EPA action level, a radon vent is one of the most common pieces of equipment an inspector will see. Knowing what correct looks like lets homeowners and buyers spot problems early. The radon testing hub covers how to test before and after any vent work.
References
- Consumer’s Guide to Radon Reduction: How to Fix Your Home — U.S. Environmental Protection Agency
- Radon — U.S. Environmental Protection Agency
- Radon Program — Colorado Department of Public Health and Environment
- InterNACHI home inspection resources — International Association of Certified Home Inspectors
- Radon and Lung Health — American Lung Association
Frequently asked questions
What does a radon vent do?
A radon vent carries soil gas from a suction point under the foundation up and out above the roof edge, where it disperses safely. In an active system a fan pulls the gas through the pipe continuously; in a passive system warm-air buoyancy moves it.
What size pipe is used for a radon vent?
Most radon vents use 3-inch or 4-inch Schedule 40 PVC. Four-inch pipe moves air with less resistance and noise, while 3-inch pipe fits tighter interior chases.
Can a radon vent fan be installed in the basement?
No. The fan must be outside the living space and not in a basement, because the pipe after the fan is under pressure and any leak would push radon indoors. Attics, garages and exterior walls are the accepted locations.
Does a passive radon vent work?
It lowers radon somewhat, but often not enough in high-radon areas like the Front Range. If a home with a passive vent tests at or above 4.0 pCi/L, adding a fan converts it to an active system.
Should a radon vent have a rain cap?
Caps that deflect exhaust downward toward the roof are discouraged by mitigation standards. The exhaust should discharge upward and unobstructed, and rain that enters simply drains back through the pipe to the soil.
How can you tell a radon vent fan is working?
Check the manometer on the pipe. Uneven liquid levels mean the fan is creating suction; level liquid means the fan has stopped or the pipe is disconnected.
Why is water dripping from my radon vent?
Warm, humid soil gas condenses in a cold pipe, and some water drips at the exhaust or drains back to the slab. That is normal, but pooled water or heavy icing points to a slope or insulation problem.
