Radiant Barrier: Does It Help in Colorado Attics?

We may earn commission from links on this page. Lead-form submissions are forwarded to local inspector partners. How we research and review.

A radiant barrier is a sheet of highly reflective material, usually aluminum foil laminated to kraft paper, plastic film or the underside of roof sheathing, that is installed in an attic to cut down on radiant heat moving from a sun-baked roof into the space below. Sales pitches for these products often promise dramatic drops in cooling bills, and the technology is real: in hot, sunny climates a properly installed barrier can lower attic temperatures and reduce the heat that reaches ceiling insulation. The results depend heavily on climate, on how much insulation the attic already has and on where and how the foil is installed, however. Colorado’s Front Range is a heating-dominated climate with cold winters and relatively short cooling seasons, so the case for a radiant barrier here is weaker than in Phoenix or Houston. This guide explains how radiant barriers work, what federal research has measured, where the foil belongs in the attic, how it interacts with insulation and ventilation, what can go wrong, and what installation typically costs, so homeowners and buyers can judge whether the upgrade makes sense for a particular house.

Part of our Crawl Space & Attic Guide guide — start there for the full picture →

How a Radiant Barrier Works

Heat moves in three ways: conduction through solid materials, convection through moving air, and radiation across open space. Conventional insulation such as fiberglass, cellulose and mineral wool mainly slows conduction and convection by trapping air. A radiant barrier works differently. It targets radiant heat, the infrared energy that a hot roof deck gives off toward cooler surfaces below it.

On a summer afternoon, roof shingles absorb sunlight and heat up, and that heat conducts through the roof sheathing. The underside of the sheathing then radiates heat downward into the attic, warming the attic air, ductwork and the top of the ceiling insulation. A radiant barrier interrupts that radiant transfer in two ways. A reflective surface facing an air space reflects much of the infrared energy that strikes it, and a low-emittance surface gives off less radiant heat itself, even when it is warm.

The Department of Energy’s Insulation Fact Sheet, hosted by ENERGY STAR, describes a single reflective surface facing an open space such as an attic as a radiant barrier, and states that radiant barriers must have a low emittance of 0.1 or less and a high reflectance of 0.9 or more. The same fact sheet says radiant barriers are installed to reduce summer heat gain and winter heat loss.

The key requirement is an air space. A foil sheet sandwiched tightly between two solid materials has little radiant effect because there is no open gap for infrared energy to cross. That is why radiant barriers are installed facing into the open attic, not buried inside an assembly.

What the Research Shows, and Why Climate Matters

Most of the strongest evidence for radiant barriers comes from hot, sunny, cooling-dominated regions. A U.S. Department of Energy Building America study, Internal Roof and Attic Thermal Radiation Control Retrofit Strategies for Cooling-Dominated Climates (Fraunhofer Center for Sustainable Energy Systems, 2013), tested a multi-foil radiant barrier and spray-applied radiation control coatings in occupied duplexes in Austin, Texas. The researchers recorded a 3.4°C (about 6°F) reduction in average attic air temperature with the radiant barrier during mid-summer and estimated a 34% reduction in attic-generated cooling loads. Because roofs and attics account for only part of a home’s total cooling load, the report estimated potential whole-building cooling energy savings of about 4%, and its calibrated computer model predicted lower savings still, around 1.3%.

The report also summarized an earlier review of prior radiant barrier research that found summer ceiling heat load reductions of 23% to 45%, with winter heat load reductions equal to roughly 40% of the summer reduction. In the report’s payback analysis, the shortest paybacks were in Miami and Phoenix.

Several lessons carry over to Colorado:

• Cooling savings are the main benefit. Radiant barriers do most of their work when the roof is hot and the air conditioner is running. Front Range homes have a meaningful cooling season, but it is shorter than in the southern states where the research was done.
• Winter benefit is smaller. The research summarized in the DOE report suggests winter reductions are a fraction of summer reductions, and most Colorado homes typically spend more on heating than on cooling over a year.
• Insulation level changes the math. A well-insulated attic floor already slows most heat flow into the living space, which leaves less heat for a radiant barrier to block. The attic itself may still get cooler, but the effect on room temperatures and utility bills shrinks.
• Ducts in the attic are a special case. If ductwork runs through a hot attic, lowering attic air temperature can reduce heat gain into the ducts, which may produce more noticeable comfort improvements than the ceiling alone would suggest.

The practical takeaway for Front Range homeowners is that a radiant barrier may produce modest cooling savings, particularly in homes with west-facing upper rooms, attic ductwork or dark roofs, but it is rarely the first or most cost-effective attic upgrade. Savings estimates from sellers that are based on Sun Belt data should be treated cautiously.

Altitude and Colorado Sunshine

Colorado’s high elevation and frequent clear skies mean strong sunshine on roofs, even on cool days. That intensity can make attics surprisingly warm in spring and fall, which is one reason radiant barriers are marketed in the state. Whether that translates to meaningful savings depends on the home. In a heating-dominated climate, a warmer attic on a sunny winter day may even slightly reduce heat loss through the ceiling, and a radiant barrier can block some of that free warmth. The net annual effect is hard to predict without modeling a specific house, and no single number applies across the Front Range.

Where the Foil Goes: Installation Options

Placement matters as much as the product itself. The DOE Insulation Fact Sheet notes that radiant barriers are most often attached near the roof, to the bottom surface of the attic truss chords or to the rafter framing, and that they must be installed according to the manufacturer’s instructions.

Foil-Faced Roof Sheathing (New Construction or Reroofing)

In new construction, the simplest approach is roof sheathing with a factory-laminated foil face installed with the foil facing down into the attic. The fact sheet mentions foil-faced wood products for roof sheathing as a way to make the radiant barrier an integral part of the structure. Because the foil is already attached, there is no separate labor step, and the incremental cost is usually small. Homeowners replacing a roof down to the deck can sometimes request foil-faced panels; the roof sheathing guide covers how decking is evaluated during a reroof.

Stapled to Rafters or Truss Chords (Retrofit)

For existing homes, the most common retrofit is to staple foil sheets to the underside of the rafters or the top chords of trusses, leaving an air gap between the foil and the roof deck above. Installers typically leave the sheet open at the bottom near the eaves and at the top near the ridge so that air can move from soffit vents to roof vents behind the foil. Working conditions are hot and cramped, especially near the eaves, and the job involves a lot of overhead stapling.

Laid on the Attic Floor

Some products are designed to be laid over the top of existing attic floor insulation. The DOE fact sheet is blunt on this point: it says a radiant barrier should never be placed on top of insulation or on the attic floor because it will soon be covered with dust and will not work. Dust on a reflective surface raises its emittance and defeats the purpose of the low-emittance foil.

A second concern with floor installations is moisture. A solid foil sheet laid over insulation acts as a vapor barrier on the cold side of the insulation in winter. Warm, moist air rising from the house can condense on the underside of the foil, wetting the insulation and potentially the drywall below. Many floor-laid products are perforated to allow vapor through, and the DOE report notes that the perforated multi-foil product used in its testing was perforated for this reason. Even so, attic-floor installations are generally the least favored option in cold climates.

How Radiant Barriers Interact With Insulation

A radiant barrier is not a substitute for adequate ceiling insulation. In a cold climate, bulk insulation does far more to keep heat in during winter, and it helps in summer too. ENERGY STAR’s Recommended Home Insulation R-Values table lists R60 for an uninsulated attic floor in climate zones 5 through 8, and R49 to add where an attic already has 3 to 4 inches. Much of the Front Range falls in climate zone 5, with higher mountain areas in zones 6 and 7.

That means a typical Colorado attic with only a few inches of old fiberglass will usually see larger benefits from topping up insulation than from adding foil. The attic insulation guide explains how to measure existing depth and estimate R-value, and the ceiling insulation guide covers attic floors and cathedral ceilings. For readers comparing broader insulation strategies across the house, the crawl space insulation pillar and the crawl space hub cover the other end of the building envelope.

Air sealing comes before both. Gaps around light fixtures, plumbing stacks, top plates and attic hatches let warm, moist indoor air into the attic, which wastes energy and can lead to frost and ice dams. ENERGY STAR’s Attic Air Sealing Project notes that air sealing combined with attic insulation can help alleviate ice dams in winter. Installing a radiant barrier on the rafters before air sealing and insulation work is done can also make later access to the eaves harder, so sequencing matters.

Ventilation, Roof Temperatures and Moisture

Radiant barriers attached to the roof framing change how heat moves in the space between the foil and the roof deck. Because the foil reflects heat back toward the deck, the sheathing and shingles may run somewhat warmer than they would without it. How much warmer, and whether that matters for shingle life, depends on factors such as ventilation and roof color, so homeowners should check that a radiant barrier installation does not void the roofing warranty and does not block airflow.

Ventilation is the other half of the system. Most vented attics rely on intake vents at the soffits and exhaust vents at or near the ridge. A radiant barrier stapled to the rafters must leave a clear channel from the soffit to the ridge so outside air can sweep heat and moisture out of the space behind the foil. A barrier that seals off the eaves or covers ridge vents can trap heat against the deck and trap moisture in winter. The attic ventilation guide explains balanced intake and exhaust, and the soffit vents guide covers the intake side in detail.

Powered and solar fans are sometimes sold together with radiant barriers. Fans can pull conditioned air from the house into the attic through ceiling leaks if the ceiling is not well sealed, which can offset any savings. The solar attic fan guide explains when these fans help and when they backfire.

Moisture Warning Signs

Signs that an attic with a radiant barrier may have a moisture problem include:

• Frost on the underside of the foil or roof nails in winter.
• Water staining or darkening on sheathing visible at the edges of the foil.
• Damp, matted or stained insulation under a floor-laid barrier.
• Ceiling stains in rooms below, especially near exterior walls.
• Mold growth on framing near the eaves.

Any of these warrants a closer look at air sealing, bath fan venting and ventilation paths before more products are added.

Safety, Inspection and Common Installation Problems

Radiant barrier work happens in some of the most uncomfortable and hazardous parts of a house. Attics can reach extreme temperatures in summer, footing is limited to joists or trusses, and roofing nails protrude through the deck overhead. Electrical hazards are a specific concern with foil. The DOE Insulation Fact Sheet notes that reflective foil conducts electricity and advises avoiding contact with any bare electrical wiring. Older homes with knob-and-tube wiring or damaged cable insulation need extra care, and an electrician’s evaluation may be appropriate before foil is installed nearby.

ENERGY STAR’s air sealing guidance also cautions that some attics contain vermiculite insulation, which may contain asbestos, and should not be disturbed unless it has been tested. That caution applies to any attic project, including radiant barrier installation.

Home inspectors evaluating an attic with a radiant barrier commonly note conditions such as:

• Foil laid directly on top of insulation, especially solid (unperforated) sheets.
• Foil blocking soffit vents, gable vents or ridge vents.
• Torn, sagging or partially detached sheets.
• Foil in contact with exposed wiring, junction boxes or recessed light housings.
• Foil installed too close to furnace or water heater flues, where clearance requirements apply.

Radiant Barrier Costs

Costs vary with attic size and pitch, access, the product chosen and whether the work is a standalone retrofit or part of a larger project. Figures below are rough, hedged ranges for planning, not quotes.

• DIY foil sheets: Rolls of perforated radiant barrier foil are relatively inexpensive per square foot, so materials for a typical attic often cost a few hundred dollars. Labor is the homeowner’s time in difficult conditions.
• Professional rafter-attached installation: Contractor-installed radiant barriers in an existing attic commonly run in the range of several hundred dollars to a couple of thousand dollars, depending on square footage, roof complexity and regional labor rates.
• Foil-faced roof sheathing: During new construction or full reroofing with new decking, the upcharge for foil-faced panels over standard OSB is usually modest compared with a separate retrofit.
• Spray coatings: Low-emittance coatings sprayed on the underside of the deck, which the DOE study found reduced attic temperature less than foil, are typically priced per square foot of coverage.

Because the energy savings in Colorado are likely to be modest, payback periods can be long. Comparing radiant barrier quotes against the cost of air sealing and adding insulation is usually worthwhile. The attic insulation cost guide outlines typical prices for those upgrades.

Questions to Ask Before Buying

• What are the product’s emittance and reflectance values, and do they meet the 0.1 or less and 0.9 or more thresholds in DOE guidance?
• Where will it be installed: rafters, truss chords or attic floor?
• How will ventilation paths from soffits to ridge be preserved?
• Are the savings estimates based on Colorado conditions or on Sun Belt data?

A radiant barrier is a real technology with measured benefits, but those benefits are largest in hot, sunny, cooling-dominated climates. On the Front Range, air sealing, adequate ceiling insulation and balanced ventilation usually deliver more value per dollar, and a radiant barrier is best viewed as a possible add-on for specific situations such as attic ductwork or hot upstairs rooms rather than a primary upgrade.

References

• Insulation Fact Sheet (DOE/CE-0180) — U.S. Department of Energy, hosted by ENERGY STAR
• Internal Roof and Attic Thermal Radiation Control Retrofit Strategies for Cooling-Dominated Climates — U.S. Department of Energy Building America Program
• Recommended Home Insulation R-Values — ENERGY STAR
• Attic Air Sealing Project — ENERGY STAR
