Double Hung Windows: Balances, Sashes and Common Failures

We may earn commission from links on this page. Lead-form submissions are forwarded to local inspector partners. How we research and review.

Double hung windows are the classic American window: two sashes stacked in one frame, each able to slide up or down. They show up in Denver’s century-old bungalows and Victorians, in 1950s ranches across Lakewood and Aurora, and in countless newer homes along the Front Range. The basic design has lasted because it is simple, fits traditional architecture and ventilates well. But the parts that make it work, from balances and jamb liners to locks and weatherstripping, wear out, and the problems they cause are among the most common window items in an inspection report. This guide explains how the sashes and balances work, how tilt-in cleaning functions, what to expect from old windows with sash cords, which failures show up most often, how egress and child safety apply, what ENERGY STAR certification means and what repair or replacement generally costs. Figures are general 2026 estimates.

Part of our Structure & Exterior guide — start there for the full picture →

How Double Hung Windows Work

A double hung window has an upper sash and a lower sash that both slide vertically within the frame. Opening the lower sash lets air in at the bottom; lowering the upper sash lets warm air escape at the top; opening both at once can set up a gentle convection flow through the room. That flexibility is the main functional difference from a single-hung window, in which only the lower sash moves and the upper sash is fixed.

The main parts are worth knowing because inspection reports and repair quotes refer to them by name:

• Frame. The head (top), jambs (sides) and sill (bottom) that hold everything in the wall opening.
• Sashes. The movable frames that hold the glass. Each has top and bottom rails and two stiles.
• Meeting rail (check rail). Where the bottom rail of the upper sash meets the top rail of the lower sash. The sash lock usually sits here.
• Jamb liners or channels. The tracks the sashes slide in. On many modern windows these are vinyl or compressible liners that also seal the sash edges.
• Balances. The springs, weights or cords that counteract the weight of each sash so it stays where it is put.
• Weatherstripping. Seals at the meeting rail, sill and jambs that limit air leakage.
• Glazing. Single panes in old windows; sealed double- or triple-pane insulating glass units in most newer ones.

Balances: Sash Weights, Spring and Block-and-Tackle Systems

Without a balance, a sash would slide down on its own the moment the lock was released. The balance is the part that makes a double hung window usable, and it is also one of the parts most likely to fail.

Sash weights and cords

Older wood windows, roughly those built before the mid-20th century, typically use cast-iron or lead weights hanging inside hollow pockets in the jambs. A cord or chain runs from each side of the sash over a pulley at the top of the jamb down to the weight. When a cord breaks, which is common after decades, the sash slams down or will not stay open. Replacing cords is a traditional repair: a pocket cover in the jamb is opened, the weight is retrieved and a new cord or chain is installed. These windows can last for generations when maintained, though the weight pockets are often uninsulated and leaky.

Spiral (tube) balances

Spiral balances use a twisted rod inside a tube, with a spring that resists the sash’s weight. They are compact and common in vinyl and wood replacement windows. When the spring loses tension or a connection breaks, the sash may drift down or feel heavy.

Block-and-tackle (channel) balances

Block-and-tackle balances use a spring and a cord running through a set of small pulleys inside a metal channel in the jamb. They are widely used in older aluminum and vinyl windows. Common failures include a snapped cord, a broken spring or a cracked pulley housing. Replacement parts are usually available if the size and weight rating can be matched.

Constant-force coil balances

Some windows use flat coiled springs, similar to a tape measure, mounted in the jamb and attached to the sash. They exert a consistent force through the sash’s travel and are common on heavier sashes.

Most balance repairs are manageable for a handy owner or a window repair technician, but spring balances store energy and can snap back. Matching the correct replacement to the sash weight and window height matters; an undersized balance lets the sash drop, while an oversized one makes it creep upward.

Tilt-In Sashes and Cleaning

Many modern double hung windows let each sash tilt inward for cleaning, which is a major convenience on second-floor windows. Tilt latches at the top of each sash retract to release the sash from the jamb channels. The sash then pivots on pins near its bottom corners, which ride in balance shoes or cams in the jamb.

The usual sequence is to raise the lower sash a few inches, release both tilt latches and tip the sash inward until it rests flat. The upper sash is usually lowered near the sill before it is tilted. Manufacturers’ instructions differ, so it is worth checking the specific window before forcing anything.

Problems with tilt-in windows often show up during cleaning: a pivot pin snaps, a balance shoe unlocks and shoots up the channel, or a latch breaks. A sash that will not seat back into the channels or that sits crooked afterward usually has a balance shoe that has come out of position. These are typically repairable without replacing the whole window.

Old Windows With Sash Cords

Original wood double hung windows in older Denver neighborhoods are worth special attention. Many are made of old-growth lumber that resists decay better than some modern wood, and with new cords, weatherstripping and glazing putty they can perform respectably, especially when paired with storm windows. They also have common issues:

• Painted-shut sashes. Decades of paint can glue sashes to stops and parting beads.
• Broken cords. One or both sashes will not stay up.
• Loose or missing glazing putty. Lets water in and panes rattle.
• Sill and bottom-rail rot. Water collects where the sash meets the sill.
• Air leakage around the sashes and through weight pockets.

Whether to restore or replace original windows is partly a question of condition and partly one of priorities. Owners of historic homes, including those in designated Denver historic districts where exterior changes may need review, often keep original sashes and add interior or exterior storm windows to cut drafts. Others prefer the convenience of tilt-in replacement units. Getting quotes for both paths, with the same scope of work, makes the comparison clearer.

Lead paint is a key concern with these windows. The EPA’s Renovation, Repair and Painting Program page notes that approximately three-quarters of U.S. homes built before 1978 still contain some lead-based paint, and that old or worn lead-based paint, especially on surfaces subject to constant friction like doors or window sills, can produce chips and dust that become a hazard. Every time an old painted sash slides in its channel, it can grind paint. The RRP Rule requires that paid contractors disturbing paint in pre-1978 homes be certified in lead-safe work practices. Restoring old sashes, freeing painted-shut windows or replacing them should follow lead-safe practices. Our window sash replacement guide covers when to restore a sash and when to replace it.

Common Double Hung Window Failures

Stuck or hard-to-move sashes

Paint, swollen wood, dirt in the channels, warped vinyl or failed balances all make sashes hard to move. A window that cannot be opened is more than an inconvenience; in a bedroom it can compromise emergency escape. Cleaning the channels, adjusting or replacing balances, and carefully freeing paint are typical fixes.

Failed insulating glass seals

Insulating glass units are sealed at the edges. When the seal fails, moist air enters the space between panes, and fogging, streaks or mineral deposits appear that cannot be cleaned off. The window still works, but some insulating value is lost and the view is impaired. The ASHI Standard of Practice calls for inspecting a representative number of doors and windows, but states that inspectors are not required to inspect coatings on and the hermetic seals between panes of window glass. That means a report may mention visible fogging, but it should not be read as a guarantee that every seal is intact, since failed seals are not always visible depending on light and temperature.

Drafts

Air leakage at the meeting rail, along the jambs and at the sill is common, especially when the sash lock does not pull the rails tightly together or the weatherstripping is worn. On older windows, the weight pockets can also be a path for air. Our guide to drafty windows explains how to find and address leaks.

Condensation and rot

Condensation on the room side of the glass often points to high indoor humidity rather than a defective window. The EPA’s Brief Guide to Mold, Moisture and Your Home suggests keeping indoor humidity below 60 percent, ideally between 30 and 50 percent, and advises acting quickly to dry surfaces and reduce the moisture source when condensation collects on windows. Repeated condensation running down to the sill can stain and rot wood sashes and sills over time. Exterior rot at sills and bottom rails usually results from failed paint and water sitting on horizontal surfaces.

Broken locks and hardware

Sash locks that do not engage, missing tilt latches and broken lift handles affect security and air sealing. Replacement hardware is often available by brand.

Egress and Window Fall Safety

Egress

Bedrooms and some basement rooms need an emergency escape and rescue opening, and a window often serves that role. Double hung windows present a particular challenge: because only half of the window opens at a time, the clear opening is roughly half the window’s height. A window that looks large may still have a net clear opening below what the building code requires for egress. Widely adopted residential codes set minimums for net clear opening area, height and width and a maximum sill height above the floor, and local jurisdictions adopt and amend those requirements. Basement bedrooms are where shortfalls are most common. Inspectors often note bedroom windows that appear undersized or have sills too high. The egress window installation cost guide covers what it takes to bring an opening into line. Where egress is a priority, a casement window, which opens fully, may provide a larger clear opening in the same rough size.

Preventing window falls

Window falls are a serious risk for young children. In an April 2026 release for National Window Safety Week, the U.S. Consumer Product Safety Commission reported that an estimated 5,600 children aged 12 and under were treated in emergency departments in 2024 after falling out of a window, with about one in three requiring hospitalization. CPSC also reported awareness of at least 25 deaths among children 12 and under from window falls between 2021 and 2023, with 80 percent occurring between May and October.

CPSC’s recommendations include installing window guards, installing window stops so windows open no more than four inches, never depending on screens to keep children from falling, and opening windows from the top instead of the bottom whenever possible. That last tip fits double hung windows well: lowering the upper sash ventilates a room while keeping the opening out of a small child’s reach. Window guards installed on windows used for egress should be the type adults and older children can release quickly in an emergency, as CPSC notes. See our window guards guide for product types.

Energy Efficiency and ENERGY STAR

Double hung windows are not inherently more or less efficient than other styles, but they have more sliding joints than a fixed or casement window, which compress against a seal when closed. Quality weatherstripping and a lock that pulls the meeting rails together matter.

According to ENERGY STAR’s key product criteria, certified windows are made by an ENERGY STAR partner, are independently tested, certified and verified by the National Fenestration Rating Council (NFRC), and have NFRC ratings that meet efficiency guidelines set by EPA. Performance criteria vary by climate zone. The same page notes that ENERGY STAR does not require any specific technologies, and it describes common frame materials, including fiberglass, vinyl, aluminum with thermal breaks, wood and clad wood, and composites.

The NFRC label on a new window lists ratings such as U-factor and solar heat gain coefficient, which make comparisons easier than marketing language. Our energy-efficient windows guide explains how to read those numbers for Front Range conditions.

Repair and Replacement Costs

Costs vary widely with window size, material, brand, access and whether the work involves lead-safe practices. As broad 2026 estimates:

• Balance replacement is usually one of the less expensive window repairs, often a modest parts cost plus labor if a technician does the work.
• Sash cord repair on old wood windows is commonly priced per window and goes up when sashes are painted shut or need reglazing.
• Insulating glass unit replacement can sometimes be done without replacing the whole window, depending on the design and availability of glass.
• Sash replacement kits fit new sashes and jamb liners into existing frames, a middle-ground option for sound frames.
• Full window replacement ranges from relatively economical vinyl insert units to substantially more expensive fiberglass, wood or clad-wood windows and full-frame installations.

The window replacement cost guide breaks down how style, material and installation method affect price.

What Inspectors Check on Double Hung Windows

During a general home inspection, an inspector typically operates a representative sample of windows, checking that sashes open, stay open and close, that locks engage, and that glass is intact. Reports often note stuck or painted-shut sashes, failed balances, broken locks, visible fogging between panes, rot at sills, missing screens, and bedroom windows that may not meet egress expectations. Inspectors also look at the exterior trim, flashing and caulking around windows. The hiring process guide explains inspection scope, and the structure and exterior hub collects related window, siding and roofing guides.

References

• CPSC Urges Families to Protect Children During National Window Safety Week — U.S. Consumer Product Safety Commission
• What Makes It ENERGY STAR? Windows, Doors and Skylights — ENERGY STAR
• Lead Renovation, Repair and Painting Program — U.S. Environmental Protection Agency
• A Brief Guide to Mold, Moisture and Your Home — U.S. Environmental Protection Agency
• ASHI Standard of Practice for Home Inspections — American Society of Home Inspectors
