What is thermal imagery? The term refers specifically to the output of infrared sensing — the still images and video frames that a thermal camera produces — rather than the camera itself. A single still is called a thermogram. A sequence of thermograms is thermal video. The distinction matters because the interpretation of thermal imagery is a separate skill from the operation of the camera, and the imagery itself has properties (palette choice, span and level, radiometric metadata) that affect what the viewer sees. This guide explains thermal imagery as a visual artifact: what it is, what it looks like, and how to read one without making the common interpretation mistakes.
Part of our Thermal Imaging for Homes guide — start there for the full picture →
Thermal Imagery Defined
Thermal imagery is a two-dimensional false-color representation of surface temperatures across a scene, produced by an infrared imaging sensor. The image is not a photograph of light. It is a map of radiated infrared energy, converted to a color scale that the human eye can interpret. Each pixel in the image corresponds to a single temperature reading at a specific location in the scene, taken at one instant in time. A typical handheld inspection camera produces thermograms with 80×60 to 640×512 thermal pixels — small by photographic standards, but each pixel carries information that no visible-light camera can capture.
The U.S. Department of Energy refers to thermal imagery as “thermograms” in its energy-saver guidance and emphasizes that a single thermogram is a snapshot of a moment, not a definitive answer. Confirming the meaning of a thermal image typically requires additional measurements with a moisture meter, a clamp meter, or a borescope.
What a Thermogram Actually Shows
The first thing to know about a thermogram is that the colors are arbitrary. They are not the colors of the objects in the scene; they are an assigned palette mapped to a temperature range chosen by the operator. The most common palette is “iron,” which runs black-purple-red-yellow-white for ascending temperatures. Other palettes — rainbow, grayscale, high-contrast — present the same data in different visual codes. A homeowner shown a thermogram for the first time often misreads the colors as somehow representing material or moisture; they represent only temperature, scaled to the image’s span and level.
A second non-obvious property is that thermograms show emitted infrared radiation, modulated by surface emissivity. A shiny metal duct can appear deceptively cold because it has low emissivity — its surface radiates very little of its own heat and instead reflects the cooler radiation of surrounding objects. A matte black painted ceiling, with emissivity near 0.95, shows close to its true surface temperature. The same building can look very different to the imager depending on which surfaces are in view.
Palette, Span, and Level — The Three Knobs That Shape an Image
Palette
The pseudo-color scheme. Iron emphasizes hot zones in warm tones; grayscale is favored in scientific and forensic work for neutrality; rainbow is the most colorful but the hardest to read intuitively. Palette choice does not affect the underlying data on a radiometric image; only the visual presentation.
Span
The width of the temperature range mapped to the palette. A tight span — say, 5°F — maps the entire palette range to a narrow temperature window, making subtle anomalies stand out. A wide span — 50°F — flattens the image and masks small differences. Operators routinely adjust span when investigating a specific anomaly.
Level
The midpoint of the span. Sliding the level up or down moves the visible window through the temperature range without changing its width. Useful for centering on a hot or cold target without changing the contrast.
Radiometric Imagery vs Non-Radiometric Imagery
The most important technical distinction in thermal imagery is whether each pixel stores a real temperature value or only a color. Radiometric thermograms carry per-pixel temperature data as metadata; non-radiometric thermograms store only the rendered JPEG with no recoverable temperatures.
Radiometric imagery can be re-analyzed in desktop software. The operator can adjust emissivity, palette, span, and level after the fact, drop in spot-measurement crosshairs, and produce reports with annotated temperature readings at specific points. Non-radiometric imagery is locked at capture — what the operator saw on the camera display is exactly what the report viewer sees. For any documentation work (insurance claims, real-estate disclosures, energy-audit certifications), radiometric output is mandatory.
How a Thermogram Is Read
Reading a thermogram involves four steps. First, identify the scene — what surface is the camera looking at, from what angle, in what ambient conditions. A thermogram of an attic floor from below tells a different story than the same area imaged from above. Second, identify the temperature delta — the difference between hot and cold zones in the image. A small delta (1-2°F) is hard to interpret with confidence; a large delta (10°F+) gives stronger evidence. Third, identify potential causes for each anomaly — missing insulation, air infiltration, thermal bridging, plumbing line behind drywall, moisture intrusion, electrical resistance heating. Fourth, plan a confirming measurement: a moisture meter probe, an outlet plate removal, a borescope insertion.
InterNACHI training material teaches that the imager raises hypotheses; other instruments confirm or rule them out. A thermogram on its own is rarely sufficient evidence for a major repair decision.
Common Patterns and What They Usually Mean
Vertical Stripes on a Ceiling or Wall
Usually mark stud or joist positions, where the wood acts as a thermal bridge through the insulation. The stripes are not a defect; they are normal building behavior. A real defect would be missing stripes (where insulation has slumped out of a single bay) or unusually wide stripes.
Cold Plumes Around Windows, Doors, and Floor Penetrations
Indicate air infiltration. The thermogram shows the cold air spilling into the room and pooling on adjacent surfaces. Pair with a blower door for a quantitative leak estimate.
Cool Patches with Soft Boundaries
Often indicate moisture. Evaporation from a wet surface pulls heat away, producing a cooler reading than the surrounding dry material. The boundary tends to be irregular and gradient, not sharp. Confirm with a moisture meter before assuming.
Hot Spots in Electrical Panels
A single breaker, lug, or connection significantly warmer than its peers indicates loose connection, overload, or developing failure. OSHA electrical safety guidance recognizes thermography as a standard predictive-maintenance technique for electrical equipment.
Symmetric Warm Halos Around HVAC Registers
Normal during a heating or cooling cycle. The warm or cool air spreads radially from the register. An asymmetric pattern can suggest a damper problem or ductwork imbalance.
Time-of-Day Effects on Thermal Imagery
The same wall produces dramatically different thermograms depending on when the image is captured. Early morning, after a cool night, indoor heating creates a strong outside-to-inside temperature differential, making cold infiltration zones obvious on interior thermograms. Mid-afternoon in summer, exterior walls sun-loaded above ambient can mask the very features the operator is trying to find. Late evening before sunrise the next morning often produces the cleanest thermograms because solar loading has dissipated and HVAC cycling stabilizes the indoor environment.
Working thermographers schedule whole-house energy surveys for early morning or after sunset. For electrical-panel scans the timing matters less because the panel’s internal temperature is driven by current draw rather than solar loading. For roof and exterior wall surveys, timing is critical.
Multi-Frame Thermal Imagery: Video and Time-Series
A single still thermogram captures one instant. Many diagnostic questions are better answered by a sequence of frames. Thermal video — typically 9 Hz on consumer hardware, 30-60 Hz on professional — shows how temperature patterns develop over time. A leaking pipe behind drywall produces a slowly-developing cold spot that becomes more visible after the heating system has cycled. A failing electrical connection produces a hot spot that grows under load. Time-series imagery captures dynamics that single stills miss.
Many modern thermography software platforms support time-lapse stacking, where multiple frames captured over hours or days are stitched into a single sequence. For energy-audit work this can reveal cycling patterns invisible in any single frame.
Limits of Thermal Imagery
A thermogram of a window does not reveal what is on the other side of the glass — standard glass is opaque to long-wave infrared. A thermogram of a wall does not show what is inside the wall — surface temperature patterns imply but do not depict the interior. A thermogram taken under low temperature delta (a mild day, an unconditioned space) often shows nothing useful even when problems exist. ASHRAE methodology recommends at least about a 10°F differential across the building envelope before drawing conclusions. For more on the device producing the imagery see our infrared thermal imager guide and the parent home inspection tools hub.
Thermal Imagery in Inspection Reports
A thermogram included in an inspection report should be accompanied by a visual-light image of the same view, the camera model and resolution, the date and ambient conditions, the emissivity setting used, and a brief interpretive note. A thermogram alone — without context — leaves the reader unable to evaluate the finding. The InterNACHI Infrared Certified standard of practice gives a structured format for including thermal imagery in inspection deliverables.
Storage and Sharing of Thermal Imagery
Radiometric thermal files are larger than standard JPEGs because of the per-pixel temperature metadata. Manufacturers use proprietary formats (.seq, .jpg with embedded radiometric metadata, .img) that require the manufacturer’s free or paid desktop software to open. Stripping the metadata to share a flat JPEG loses the analytical value, which is why distributing the original file matters when a second opinion is needed.
How to Compare Two Thermal Images of the Same Scene
Comparing thermal images across time — for example, a baseline thermogram from move-in followed by a follow-up six months later — is a useful technique for confirming or ruling out developing problems. The comparison only works when the imaging conditions are matched as closely as possible. Same camera, same lens, same approximate distance, same emissivity setting, same span and level, same indoor and outdoor temperatures. Any of these variables shifting produces apparent differences that have nothing to do with the actual condition of the building.
For repeat-visit thermography in research or industrial-monitoring contexts, manufacturers offer documentation templates that capture each setting variable systematically. For residential inspection work, hand-noting the variables alongside each image is sufficient.
Common Misreading Patterns by Untrained Viewers
Untrained viewers of thermal imagery routinely misinterpret what they see. The most common misreading is treating bright colors as definitive evidence of damage when the bright color may simply reflect a tight palette span centered on an ordinary temperature. A second common misread is interpreting normal thermal bridges (stud lines, joist patterns) as missing insulation. A third is treating the boundary between conditioned and unconditioned spaces (warm room vs cold garage) as a defect when it is the normal building physics. A fourth is confusing reflective surfaces (windows, polished metal) for cold zones when they are actually reflecting cooler surrounding objects.
Inspection reports that include thermal imagery typically pair each image with a short interpretive caption explaining what the operator is reporting and ruling out the obvious alternative interpretations.
