Door Headers: Sagging Openings, Cracks and Load-Bearing Walls

We may earn commission from links on this page. Lead-form submissions are forwarded to local inspector partners. How we research and review.

Every doorway in a framed wall is a gap in the studs, and something has to carry whatever the missing studs would have supported. That something is the header: a beam across the top of the opening that collects the load from above and delivers it to the framing at each side. Most people never think about headers until a door starts sticking, a diagonal crack appears at the corner of a doorway, or a remodel plan calls for widening an opening or removing a wall. Then the header becomes the most important piece of wood in the conversation. This guide explains what a header does, how load-bearing and non-bearing walls differ, how headers are sized, the warning signs of an undersized or failing header, the permit and engineering questions around remodels, and typical costs. Header sizing is a code and engineering matter, so the figures here are general and should be confirmed with the building department or a structural engineer for any actual project.

Part of our Structure & Exterior guide — start there for the full picture →

What a Door Header Does

In a typical wood-framed wall, vertical studs carry loads from the floor, ceiling or roof above down to the floor and foundation. When a door is framed in, several studs are cut out. A header spans the opening and transfers the load sideways to the edges, where it is carried down by:

• Jack studs (trimmers). Shorter studs under each end of the header that support it directly.
• King studs. Full-height studs beside the jack studs that tie the header and the wall together and keep the assembly straight.
• Cripple studs. Short studs between the top of the header and the top plate that maintain stud spacing above the opening.

Headers are commonly built from two pieces of dimensional lumber on edge with a spacer between them, a single solid piece, or engineered lumber such as laminated veneer lumber (LVL). Exterior walls in newer homes sometimes use insulated headers to reduce heat loss through the framing.

The header is one link in a chain. FEMA’s Home Builder’s Guide to Coastal Construction (FEMA P-499) stresses that connections must provide a continuous load path, and that for the required continuous load path to be maintained, all connectors must be adequate to resist the loads expected to act on them. That guide is written for wind and flood exposure, but the principle is the same inside any house: load has to travel uninterrupted from roof to foundation, and a door opening is one of the places where the path bends.

Load-Bearing Versus Non-Bearing Walls

Whether a header carries a meaningful load depends on the wall. A load-bearing wall supports floor joists, ceiling joists, roof framing or point loads from above. A non-bearing partition wall mostly supports itself.

Clues that a wall may be load-bearing include:

• Exterior walls, which are almost always bearing in conventional framing.
• Interior walls running perpendicular to floor or ceiling joists, especially near the middle of the span.
• Walls directly above a beam, girder or another wall in the basement.
• Walls supporting a second-story wall directly above.
• Doubled or larger headers already in place over existing openings.

None of these clues is definitive. Trusses, engineered floor systems, older homes with past remodels and split-level designs common in Front Range neighborhoods can all hide unusual load paths. Before cutting into any wall, a contractor or engineer should confirm what it carries.

Non-bearing walls still need framing

A non-bearing interior wall still needs some header framing over a doorway, often a flat header or a smaller member, to support drywall and give the door frame a solid top. Problems in these walls tend to be cosmetic, such as small cracks or a door that rubs, rather than structural.

How Door Headers Are Sized

Header size depends on the span of the opening, what the wall carries, the building width, roof snow load, the lumber species and grade, and whether it is a single- or multi-story home. Residential building codes include prescriptive header tables for common situations, and engineered lumber manufacturers publish their own span tables. Larger openings, heavy point loads, or anything outside the tables call for an engineered design.

Some general patterns hold:

• Wider openings need deeper or stronger headers.
• Headers that support floors and roofs above need more capacity than those supporting a roof alone.
• Longer headers often need more than one jack stud at each end so bearing does not crush.
• Heavy snow loads, which matter in parts of Colorado, can increase roof loads that eventually reach the walls.

Because the right size depends on so many variables, it is not something to estimate by eye. A remodel plan should show the header size, and the building department reviews it at permit time.

Signs of a Sagging or Undersized Header

Header problems rarely announce themselves. They usually show up as a combination of small symptoms around the opening and the wall above:

• Diagonal cracks at the corners of the opening. Drywall and plaster crack first at the weak points, and the top corners of doors and windows are classic stress points. Some hairline cracks there are common and can come from normal seasonal movement. Cracks that widen, return after patching or show offset edges deserve more attention. Our ceiling cracks guide helps sort cosmetic from structural cracking.
• A door that sticks at the top or will not latch. If the head jamb sags or the opening racks out of square, the door may rub at the top corner or the latch may no longer line up with the strike plate. See our door won’t latch guide for causes and fixes.
• An uneven gap around the door. A gap that tapers along the top or one side suggests the frame has shifted.
• Visible sag in the head trim or the ceiling above. A level held against the trim or a long straightedge on the ceiling can reveal deflection.
• Sloping floors above the opening. When a header carries a floor, sag can show up as a dip in the floor above.
• Crushed or split framing at the ends, visible in unfinished basements or during remodels.

Header problem or foundation movement?

Many of the same symptoms come from foundation movement rather than a header. Along the Front Range, expansive clay soils can lift and drop parts of a foundation seasonally, which racks door openings even when the header is sized correctly. Cracks that line up from foundation to framing, multiple doors sticking on one side of the house, and stair-step cracks in block or brick point toward the foundation. Our foundation cracks guide explains how to read those patterns. Distinguishing the two often takes a structural engineer, particularly in basements with floating walls and slip joints common in local construction.

Moisture and rot are a third cause. Exterior door headers can decay where water gets behind trim or flashing, especially over doors without overhangs. Rotted framing loses capacity and may need replacement rather than reinforcement. Problems at the base of the wall, such as a deteriorated sill, can make the whole opening settle; our sill plate guide covers that.

Remodel Risk: Widening Openings and Removing Walls

Most header trouble in existing homes traces back to a remodel. Previous owners or contractors may have widened a doorway, created an open floor plan, added a pass-through, or replaced a standard door with a wide patio door or double doors without upgrading the header. Sometimes the work happened without a permit, and the problem appears years later.

Before changing an opening in a bearing wall:

• Get a permit. Front Range building departments generally require permits for structural changes such as removing bearing walls or enlarging openings in them. The permit process includes plan review and inspections that verify the header and supports.
• Involve an engineer when needed. Long spans, point loads, beams that carry other beams, and openings in walls supporting a second story often require an engineered design, and many building departments ask for engineer-stamped plans in these cases.
• Plan temporary shoring. While the wall is opened, the loads above have to be held up with temporary walls or shoring on both sides.
• Follow the load down. A bigger header concentrates more load at each end. The jack studs, the floor below, and sometimes a new post and footing in the basement must carry it. Floor framing that already shows sag or damage may need reinforcement; our sistering joists guide explains one common approach.
• Check for hidden utilities. Walls carry wiring, plumbing, ducts and sometimes gas lines that must be rerouted.

FEMA’s building science program notes that building codes are a minimum standard and that it is essential to build above the baseline. For structural remodel work, that mindset favors a properly engineered header over the smallest member that might pass.

Unpermitted work as a buyer

For buyers, an open floor plan in an older house is worth a closer look. Ask the seller whether permits were pulled, check the local permit history if available, and look for the clues above: cracks at the ends of a new beam, a dip in the ceiling at mid-span or doors sticking nearby. An inspector cannot see inside the wall, but symptoms around the opening often tell the story.

Exterior, Patio and Garage Door Headers

Headers in exterior walls deserve extra attention because they usually carry roof loads, sometimes floor loads as well, and they are exposed to weather at the edges.

• Patio and sliding doors. These openings are wide, often 6 to 8 feet or more, so their headers are larger than those over a standard entry door. A sliding door that drags, a screen that will not track or a gap that widens at the top can hint at deflection, though worn rollers and out-of-level tracks are more common causes.
• Garage door openings. Two-car garage doors span a long distance and are frequently topped by engineered beams. Rooms above garages, common in Front Range tract homes, add floor loads. Sag at the center of the opening, cracks in drywall above, or a door that binds at mid-span are worth noting.
• Replacement doors in old openings. Swapping a single door for a wider French door or adding sidelights almost always means changing the header. That work belongs on a permit even when the door itself is the main purchase.
• Water above the door. Missing head flashing, failed caulk at trim, or a deck ledger above the door can send water into the header. Soft wood at the top corners of the exterior trim is a reason to probe further.

Common header types compared

• Built-up dimensional lumber. Two or more boards nailed together with spacers. Common, inexpensive and easy to install, but limited in span and prone to some shrinkage as the wood dries.
• Solid sawn lumber. A single deep piece, often seen in older homes. Large solid timbers can shrink and check over decades.
• Engineered lumber (LVL, PSL, glulam). Manufactured to consistent strength, so longer spans are possible in shallower members, and less prone to shrinkage. Sized from manufacturer tables or engineering.
• Steel beams or flitch plates. Used for long spans or heavy loads, usually designed by an engineer.

Shrinkage in dimensional lumber explains some of the minor cracking seen at door corners in the first year or two after construction, which is often cosmetic. Cracks that keep growing after that point are the ones to watch.

What a Home Inspector Checks

The ASHI Standard of Practice requires inspectors to inspect structural components, including the foundation and framing, and to describe the floor, wall, ceiling and roof structure. It also states that inspectors are not required to provide engineering or architectural services or analysis, or to offer an opinion about the adequacy of structural systems and components. That boundary matters for headers. An inspector will note sagging, cracks at openings, doors that bind, out-of-square frames and visible damaged framing, and will typically recommend evaluation by a structural engineer or qualified contractor when symptoms suggest a structural problem. The inspector does not calculate whether a header is the right size.

Our structure and exterior hiring guide explains when to call an engineer versus a framing contractor and how to compare their proposals. The hiring process hub covers inspectors and other trades as well.

Repair Options and Costs

Costs depend heavily on whether the wall is bearing, how wide the opening is, what finishes must be removed and whether an engineer is involved. Typical 2026 ranges, with wide regional and project variation:

• Adjusting a door and patching corner cracks where the header is sound: modest, often a handyman or carpenter visit.
• Repairing a damaged door frame or jamb: moderate; our door frame repair guide covers what that involves.
• Replacing or upgrading a header in an existing bearing wall: often in the low to mid thousands of dollars or more, including shoring, framing, drywall and trim, and higher when exterior siding is involved.
• Widening an opening or removing a bearing wall with an engineered beam: commonly several thousand dollars to well beyond, depending on span, posts, footings and finishes.
• Structural engineer evaluation: commonly a few hundred dollars or more for a site visit and letter, with design drawings costing more.

Door replacement often accompanies header work. Our guides to interior door replacement cost and exterior door replacement cost help budget for that part of the job. Get written quotes that state who is responsible for engineering, permits, shoring and finish repair.

DIY or professional?

Trimming a sticking door or adjusting a strike plate is reasonable homeowner work. Anything that removes studs, changes a header or cuts into a wall that may be load-bearing is structural work that calls for a permit and qualified professionals.

References

• ASHI Standard of Practice for Home Inspections — American Society of Home Inspectors
• Building Science — Federal Emergency Management Agency
• Home Builder’s Guide to Coastal Construction (FEMA P-499) — Federal Emergency Management Agency
